Cosmetic Three Roll Mill

Three Roll Mill Some cosmetic products, such as lipstick, nail polish, and mascara, relies on the use of a three roll mill for highly homogeneous and finely dispersed structure. Many types of mills provide high shear force are generally adopted machine in cosmetic industry. Among these, the three roll mill is the preferred mill since its advantages of uniformly applied shear force on the whole ingredients and adjustable product capacity by different designed size.

Technical Parameters

1) Model: S65 ,
2) Roller diameter: 65mm,
3) Working length: 128mm,
4) Speed(low,middle,fast): 23/66/178rpm
5) Motor power: 0.75kw

Lab-Triple-Roll-Mill-cosmetic triple-roll-mill

Pigment Three Roller Mill/pigment 3 Roll Mill/ Pigment Triple Roller

Product Description
Three Roll Mill – The three – roll grinder is the most effective grinding and dispersing equipment for high viscosity materials. Mainly used for grinding various paints, inks, paints, plastics, rubber, ceramics, cosmetics, soap and other liquid slurry and paste materials. The diameter of the roller through high precision grinding, precise and delicate, the fineness of grinding material reached about 15 m, it can produce uniform and fine quality products. The three – roller machine is used in batch production, small batch or laboratory.

Application:
Abster Lab use three roller mill is widely applied in institute experiment and trail production of paint, dye, printing ink, cosmetics, rubber, soap, high viscosity pulp, agriculture chemicals, ceramic, adhesion and grinding paste slurry etc. Laboratory three roller grinding mill is currently one of the most popular grinding mill for paint, UV ink production

Working Principle:

The equipment consists of three rollers fixed on the frame and driven directly by the motor. The rotation direction between rollers is generally different, the front roller rotates forward while the rear roller rotates backward. The speed of front roller is quicker while speed of rear roller is slower. The middle roller is fixed, and the front and rear rollers are mounted on the slide with spring device. Adjust the distance between three roll62ers by adjusting the hand wheel. The material discharged from space between rear roller and middle roller, are squeezed by the rollers to obtain smaller particle size. Then the material are rolled out by the fast roll(Roll rotates at high speed). The scrapper at the end of the fast roller separate material from the roller and fall into the collection barrels. Since it produces a lot of heat in the grinding process, the center of each roller is hollow. Input water for cooling to ensure finished products with good quality.

Machine Features

– Manually adjust roller clearance, simple and reliable structure;
– Suitable for grinding high-viscosity material;
– Cooling jacket roller design
– Hard steel roller material as standard
– Adopt gear rollers power transmission to get more stability and endurance

Technical Data

Model	Power	Roller Length	Roller Diameter	Rotation Speed	Voltage
AB65	0.75KW	128mm	65mm	23/66/178	220V/50HZ

Introduction

Product Introduction
Lab three roll mill is used for grinding and dispersing high viscosity and fineness material. It is widely used in printing inks, pigment, plastics and chocolate’s grinding test.
Material viscosity:<=3,000,000cps
Production Capacity: 0.5-5kg/h
Application Fields: Suitable for dispersing and grinding materials in industries such as ink, color paste, adhesive, biological, pharmacy, foodstuff, cosmetic, paint, photovoltaic material etc.

Working Principle

The equipment consists of three rollers fixed on the frame and driven directly by the motor. The rotation direction between rollers is generally different, the former roller rotates forward, rear roller rotates backward. The speed of former roller is quick, while speed of rear is slow. The mid roller is fixed, former and rear roller are mounted on the slide with spring devise. Adjust the distance between three rollers by hand wheel. The material, charged from space between rear roller and middle roller, are squeezed by the rollers to obtain smaller particle size. Then the material are rolled out by the fast roll(Roll rotates at high speed).The scrapper at the fast roller separate materials from the roller and fall into the collection barrels.

Features

Manually adjust roller clearance, simple and reliable structure;
Suitable for grinding high-viscosity material;
Cooling jacket roller design
Hard steel roller material as standard
Adopt gear rollers power transmission to get more stability and endurance
